点击 订货号或厂家货号了解无穷远镜头单筒视频光学系统MTDP系列下各规格产品更多参数
| 订货号 | 厂家货号 | 市场价 | 促销价 | 购买 |
| 39395 | MTDP07 | - | - | 询价 |
| 39396 | MTDP07C | - | - | 询价 |
| 39397 | MTDP10 | - | - | 询价 |
| 39398 | MTDP10C | - | - | 询价 |
| 39399 | MTDP20 | - | - | 询价 |
| 39401 | MTDP20C | - | - | 询价 |
| 39400 | MTDP30 | - | - | 询价 |
| 39402 | MTDP30C | - | - | 询价 |
| 39403 | MTDP40 | - | - | 询价 |
| 39404 | MTDP40C | - | - | 询价 |
| 39405 | MTDP50 | - | - | 询价 |
| 39406 | MTDP50C | - | - | 询价 |
| 39407 | MTDP60 | - | - | 询价 |
| 39408 | MTDP60C | - | - | 询价 |
| 39409 | MTDP80 | - | - | 询价 |
| 39410 | MTDP80C | - | - | 询价 |
主要光学参数
Form1：配1X前组物镜时的参数（工作距离：82mm）|
镜头型号 Model |
物镜倍数 |
总放大倍数(Total Mag.) |
视场 |
|
|
Obj. Mag. |
1/3"、9" |
1/3"、17" |
FOV(mm) |
|
|
MTDP07 |
0.7X |
28X |
42X |
6.9X5.1 |
|
MTDP07C |
||||
|
MTDP10 |
1.0X |
40X |
60X |
4.8X3.6 |
|
MTDP10C |
||||
|
MTDP20 |
2.0X |
80X |
120X |
2.4X1.8 |
|
MTDP20C |
||||
|
MTDP30 |
3.0X |
120X |
180X |
1.6X1.2 |
|
MTDP30C |
||||
|
MTDP40 |
4.0X |
160X |
240X |
1.2X0.9 |
|
MTDP40C |
||||
|
MTDP50 |
5.0X |
200X |
300X |
0.96X0.72 |
|
MTDP50C |
||||
|
MTDP60 |
6.0X |
240X |
360X |
0.8X0.6 |
|
MTDP60C |
||||
|
MTDP80 |
8.0X |
320X |
480X |
0.60X0.45 |
|
MTDP80C |
||||
|
前组物镜Front-end objectives |
项目 Item |
MTDP10 MTDP10C |
MTDP07 MTDP07C |
MTDP20 MTDP20C |
MTDP30 MTDP30C |
MTDP40 MTDP40C |
MTDP50 MTDP50C |
MTDP60 MTDP60C |
MTDP80 MTDP80C |
|
1X |
光学放大倍率Optical Mag. |
1.0X |
0.7X |
2.0X |
3.0X |
4.0X |
5.0X |
6.0X |
8.0X |
|
景深DOFμm |
412.4 |
589.1 |
206.2 |
137.5 |
103.1 |
82.5 |
68.7 |
51.5 |
|
|
0.3X |
光学放大倍率Optical Mag. |
0.3X |
0.21X |
0.6X |
0.9X |
1.2X |
1.5X |
1.8X |
2.4X |
|
景深DOFμm |
4597.7 |
6568.1 |
2298.9 |
459.8 |
1149.4 |
919.5 |
766.3 |
574.7 |
|
|
0.5X |
光学放大倍率Optical Mag. |
0.5X |
0.35X |
1.0X |
1.5X |
2.0X |
2.5X |
3.0X |
|
|
景深DOFμm |
1666.7 |
2381.0 |
833.3 |
555.6 |
416.7 |
333.3 |
277.8 |
208.3 |
|
|
0.75X |
光学放大倍率Optical Mag. |
0.75X |
0.5X |
1.5X |
2.3X |
3.0X |
3.8X |
4.5X |
6.0X |
|
景深DOFμm |
740.7 |
1111.1 |
370.4 |
241.5 |
185.2 |
146.2 |
123.5 |
92.6 |
|
|
1.5X |
光学放大倍率Optical Mag. |
1.5X |
1.1X |
3.0X |
4.5X |
6.0X |
7.5X |
9.0X |
12.0X |
|
景深DOFμm |
190.5 |
259.7 |
95.2 |
63.5 |
47.6 |
38.1 |
31.7 |
23.8 |
|
|
2X |
光学放大倍率Optical Mag. |
2X |
1.4X |
4.0X |
6.0X |
8.0X |
10.0X |
12.0X |
16.0X |
|
景深DOFμm |
105.3 |
150.4 |
52.6 |
35.1 |
26.3 |
21.1 |
17.5 |
|
